Trapezoidal Rods
Heavy-Duty Trapezoidal Threaded Rods for Industrial Motion & Clamping
Our trapezoidal threaded rods are designed for heavy-duty linear motion, lifting, positioning, and clamping applications. With stable thread engagement, high load capacity, and customizable material and size options, they are widely used in machinery, automation equipment, lifting devices, and industrial adjustment systems.
- DIN 103 trapezoidal thread standard available
- High load capacity for clamping and lifting systems
- Precision rolled thread with smooth engagement
- Carbon steel and stainless steel options available
High Load Capacity
Built for heavy-duty lifting, positioning and linear motion applications.
Self-Locking Design
Helps improve operational safety in lifting and motion systems.
Smooth Movement
Trapezoidal thread profile ensures stable and precise movement.
Long Service Life
Durable structure and surface options for demanding environments.
Product Description
Our trapezoidal rods are designed for heavy-duty lifting, positioning and linear motion applications. The trapezoidal thread profile provides high load capacity, stable engagement and reliable movement for demanding industrial systems.
They are widely used in industrial machinery, agricultural equipment, construction systems and automation devices. Both right-hand and left-hand thread options are available, and dimensions, surface treatment and material can be customized according to customer drawings or samples.
Product Specifications
| Product Name | Trapezoidal Rod |
|---|---|
| Application | Heavy-duty lifting, positioning and linear motion |
| Thread Type | Trapezoidal Thread |
| Thread Direction | Right-hand / Left-hand |
| Material | Carbon Steel / Stainless Steel |
| Surface | Plain / Customized |
| Features | High load capacity, self-locking design, smooth movement |
| Customization | Diameter, pitch, length, material and surface treatment |
| Standards | Customized |
Right-hand and left-hand thread options are available for different motion and assembly requirements.
Available Sizes
| Diameter (D) | Pitch | Length (L) mm | Surface | Metric Grades | Standards |
|---|---|---|---|---|---|
| T36 | P6 | 500 / 600 / 1200 / 1500 | Plain / Customized | 4.8 / 6.8 / 8.8 | Customized |
| T32 | P6 | 1600 / 2100 / 2300 | Plain / Customized | 4.8 / 6.8 / 8.8 | Customized |
| T25 | P5 | 2400 / 2600 / 2700 | Plain / Customized | 4.8 / 6.8 / 8.8 | Customized |
| T24 | P5 | 2800 / 3000 | Plain / Customized | 4.8 / 6.8 / 8.8 | Customized |
Applications
Linear Motion Systems
Lifting & Positioning Equipment
Machine Tool Adjustment
Clamping & Fixture Assemblies
Related Products
Trapezoidal Nuts
Trapezoidal Lead Screws
Threaded Rods
Coupling Nuts
Need custom sizes or specifications?
Send us your drawings, samples, or technical requirements for a quick quotation.
